Integrated Race Control Systems
TRACK VIDEO SYSTEM
Cameras
- High Speed HD-SDI PTZ cameras with no latency
- Optical zoom up to 30x
- Available as dome or PTZ camera, equipped with lens wiper
Signal Transfer
- From camera to server room via single-mode fiber: enables long-distance transmission with zero signal loss
Signal Distribution and Routing
- Centralized HD-SDI matrix provides high flexibility
- Multiple SDI inputs
- Flexible routing of signals
Video Wall in Race Control
- Large-scale video wall available in flat or curved layouts, individually tailored
- All cameras displayed Full HD resolution
- Incident screens for content requiring special attention
- Merging into a single display
Camera Operation
- All cameras can be remotely controlled from Race Control room via a 3-axial controller
- Access to each camera via unique ID numbers
- Preset positions allow instant return to predefined camera views, ensuring rapid response and increased safety
Video Wall Operation
- Customized video wall software enables configuration of the video wall, including storage and recall of presets
- User-friendly interface for intuitive operation; buttons for sources and signal destinations can be individually designed and configured
- Flexible routing of signals
Video Recording
- Video recording software specifically designed for motorsport applications
- Simultaneous recording, replay, video clip creation, and screenshot capture
- Software output (PC signal routed to the matrix) can be displayed on the video wall or on local monitors in Race Control
Integrated Race Control Systems
TECHNICAL FURNITURE
Race Control
- Custom furniture for a modern and attractive Race Control Room
- Custom tables with built-in technical devices and hidden cable/converter management
- LED illumination designed to support focus and provide lighting for both the workstations and table rears
Timekeeping
- Custom furniture for a modern and attractive Timekeeping Room
- Workstations can be individually configured to suit each event.
Speakers’ Room
- Custom furniture for a modern and attractive Speaker room
- Device panels and blank panels offer maximum flexibility in layout design
Integrated Race Control Systems
TIME KEEPING SYSTEM
Circuits
- High-performance Timekeeping Systems
- Engineered to meet FIA/FIM standards
- Reliable solutions for a range of motorsport applications
Drag Racing
- Dedicated FIA-compliant Timekeeping
- Signal Trees
Others
- Karting
- Moto Cross, incl. Start-Gates
- Rally Cross
Integrated Race Control Systems
START LIGHT SYSTEM
Start Lights
- FIA- and FIM compliant Signaling System
- Controls start and pit exit lights, their repeaters, and horns for the start grid
- Optional integration with Pit In Warning System via software
Pit Exit Lights
- Pit exit lights can also be controlled automatically or manually
- Operable via software or operator controller
Hard-& Software Controller
- Network-based system for reliable communication and control
- Prestart sequences and start procedure types configurable for each session
- Race start sequences can be set automatic or manual
Integrated Race Control Systems
LIGHT FLAG SYSTEM
EM Grade 1 Panels
- Integration of EM Motorsports FIA- and FIM Grade 1 certified Digital Flags
- Super-bright panels ensure visibility in all light conditions
- Optional Smart Marshalling – small portable onboard box informs drivers of the status of passing flags
Special G3-Panels
- Supersized, Extra-Large Panels, compliant to FIA Standard
- Manufactured by STAIDIUM TECHNOLGY
- Made not only for Races, also setting standards for tourist track days and industrial testing
Special Control Software
- Largest Installation worlwide with over 70 Panels
- Software combined with Video-Recording Software and Videowall Incident Management
- Free configurable Track Layouts
Integrated Race Control Systems
PIT IN WARNING SYSTEM
Safety Aspect
- mandatory to notify pit lane personnel of incoming vehicles
- Automatically delivers alerts to personnel in real time
Sounders and Flashlight
- Provides audible and visual warnings for enhanced safety
Induction loops
- Employs induction loop technology to detect all vehicles, including those without transponders
Integrated Race Control Systems
JUMP START DETECTION SYSTEM
For Motorcyles and Cars
- Detects jump starts in (motorcycle) races
- Cameras and red lights installed at each starting line, synchronized with the start lights
Al Kamel HD-Cams
- Precise and highly reliable detection system
RX Jump Start Systems
- Integration of RX Jump Start Systems
- ace start sequences can be set automatic or manual
Integrated Race Control Systems
PA SYSTEM
Dante-Based PA System:
- Flexible loudspeaker zoning – enables operation of independent loudspeaker groups in different areas
- Signal transmission via Single-Mode Fiber Optic – allows coverage of remote areas
- Event-oriented system design – configured in accordance with the requirements of planned Events / Race Series and customer needs
Operating
- Central Speaker Room – serves as the operational control center
- Autonomous PA System for Press Conference Area / Media Center – equipped with gooseneck and handheld microphones, audio outputs for journalists, and optional connection to the main PA network
Speaker Types
- Outdoor Loudspeakers – Column Speakers for Buildings, weatherproof high-quality Horn Speakers for harsh environments, Full-Range Systems
- Indoor Loudspeakers – Column Speakers, Ceiling Speakers, Full-Range Speakers
Integrated Race Control Systems
TV DISTRIBUTION
SMA-TV System – with Headend as Central Unit
- Signal Integration – incorporates satellite signals as well as SDI signals from racetrack-generated content, including timekeeping pages, track cameras, third-party TV feeds, and other event-specific sources.
- Optional IPTV distribution
- Signal distribution via Single-Mode Fiber Optic – enables transmission over long distances
Distribution
- Copper cabling for short-distance distribution
- TV signal distribution – coverage provided according to the requirements of major race series (e.g., Pit Wall, Garages, Commentary Booths, Paddock Club)
- Prepared for integration of external TV signals –frequencies reserved and configured in compliance with major race series requirements
Watch Anywhere
- TV signal and TV sets in Media Center – installed according to the requirements of major race series
- Prestart sequences and start procedure types configurable for each session
- Customized TV signal and installation solutions – provided as required by the client (e.g., Race Control Tower offices, Pit Building, and other venue facilities)
Integrated Race Control Systems
MARSHALL INTERCOM
AND RADIO COMMUNICATION
Radio Communication
- Enables communication from Race Control to service personnel: medical staff, flag and track marshals, blue flag marshals, fast intervention teams, track repair crews, safety teams, security teams, etc.
- Integrated network allows communication between radios, Race Control intercoms, and wired marshal stations
Tetra Cells
- Number of radio channels and radios configurable to customer requirements and tailored to event type / race series
- Race Control equipped with dispatcher and desktop panels (headsets highly recommended)
Intercom
- Additional desktop panels can be installed on site, e.g., for timekeeping or other operational needs
- Differant Brands available
- Backup wired beltpack system can be provided for marshals
Integrated Race Control Systems
INFRASTRUCTURE SYSTEMS
Outdoor & Indoor
- Outdoor Infrastructure Station with integrated Air-condition Systems
- Indoor Infrastructure Station
- Supplies devices from all the different chapters with uninterruptable power
FO Distribution
- Provides Fiber Optic connection points
- Operable via software or operator controller
UPS and FIS
- UPS and Fault Indication System
- Remote monitoring
- High performance power infrastructure
Integrated Race Control Systems
DATA NETWORK, WIRELESS DISTRIBUTION AND VoIP
Core Switch
- Core Switch – the central element of the managed network, designed to match the infrastructure of a modern racetrack and its facilities.
- A high-speed fiber-optic backbone with switches that handle full network traffic without bottlenecks.
- Solution supports QoS, fully managed firewalls and network policies, troubleshooting and common management features from end to end
(Access-) Switches
- High-performance, manageable copper switches installed in technical rooms and distribution boards across the entire facility
- The network structure is fully extensible, allowing additional devices to be integrated seamlessly.
- Secure network access for different operational areas, fully prepared for international events
Voip
- VoIP Phones in specified areas
- Centrally managed system with call manager, invoicing tool etc.
- Digital processing: system provides a high-quality voice, low noise and no latency
WiFi
- High performance wireless connection with 2,4GHz and 5GHz
- Wireless traffic controlled by managed controllers
- WIFI Access points at defined positions indoor and outdoor
Integrated Race Control Systems
CABLING
Planning
- Designed to meet international regulations and safety standards
- Complete Planning
- MTR Design
Cable Types
- Fiber Optic Cabling
- Power Cabling
- RF Cabling
- Loudspeaker Cabling
- and many more
Installation
- Cable Pulling
- Splice Works
- Testing
Integrated Race Control Systems
LED VIDEO WALLS
Experts in Planning
- We are experts in planning, supplying and implementing of multi purpose giant screens.
- Installation as fixed solution or temporary/mobile solution.
Installation
- We provide Installation Services
- Different brands for different purposes
Special Purpose
- Special purpose Screens for customers demands
- Mesh-Installation behind Windows
- Pit-Lane or Gantry Screens
